Atola Insight Forensic

Data Recovery & Digital Forensics

Atola Insight Forensic

The first and only forensic acquisition tool that works with both good and damaged media.

Up to 500 MB/sBuilt-in write blockerSATA · IDE · SAS · USB
Model
DEY-AIF
Category
Data Recovery & Digital Forensics
Request a quotation → Brochure (PDF)

3D model
by DataExpert

DEY-AIF

The interactive 3D model needs a modern browser with WebGL. Every detail it shows is listed in the specification below.

Drag to rotate Scroll to zoom Hover a marker for detail Model built to reference imagery — not a manufacturer CAD file

Detail

Atola Insight Forensic

DEY-AIF

Imaging speed means nothing if the drive will not read. Insight was built the other way round: diagnose the fault first, then work around it. Multi-pass imaging keeps returning to unreadable areas instead of stopping at them, and firmware modules can be rebuilt on a drive that will not otherwise respond.

Functions

Disk diagnostics Disk duplication Selective head imaging Password removal Segmented hashing Scripting Case management Bad sector recovery File recovery Firmware recovery Disk utilities Multi-tasking

In forensic and e-discovery cases

  • Fastest imaging speed in the industry — up to 500 MB/s
  • High performance multi-pass imaging for damaged drives
  • In-depth automatic HDD diagnostics
  • Extraction of unknown ATA passwords
  • Case management system prepares acquisition reports automatically
  • Hash calculation — MD5, SHA1, SHA224, SHA256, SHA384, SHA512
  • Forensic erasure — DoD 5220.22-M, Security Erase, NIST 800-88, Pattern Erase
  • File recovery for NTFS (all versions), Ext 2/3/4, HFS, HFS+, HFSX, ExFAT, FAT16, FAT32
  • Support for SATA, IDE, SAS and USB media
  • Built-in write blocker
  • Network forensics via SSH

Extension modules

SAS6 Gbit/s · 500 MB/s · hotplug · write protection
10 Gb Ethernet10 Gbit/s max · 400 MB/s in practice · RJ45 Cat 6
Apple PCIe SSDMacBook Pro Late 2013–2015, Air 2013–2015 · 24 GB/min
M.2 PCIe / SATAM key only · 500 MB/s · SATA full, PCIe partial
ThunderboltFireWire, TB2, TB3 · no SSD removal required

Source: Manufacturer brochure, 4 pages
